Mindstorms NXT (8527-1) is a NXT LEGO set released in 2006 with 579 pieces. Browse the parts list, minifigures, and verify loose bricks with our free scanner. This set includes 89 unique part types.
- → Read official LEGO build manuals on this page
- → Browse the full parts inventory
- → Verify loose bricks with our free part scanner
- → Check market value for parts and minifigs
Building instructions
2 official booklets — read on BrickID
BUILDING INSTR.8527,QUICKSTART BUILDING INST. 8527 V. 23
Download size:
Checking download size…
Download size unavailable
Browse the instructions on your own terms.
Parts in this set
89 parts · page 1 of 2 · updating…
-
Ball, Hard Plastic, 51mm (approx. 6 studs diameter)41250 · ×1 · Red -
Ball, Hard Plastic, 51mm (approx. 6 studs diameter)41250 · ×1 · Blue -
Cable, Connector, 20cm for NXT55804 · ×1 · Black -
Cable, Connector, 35cm for NXT55805 · ×4 · Black -
Cable, Connector, 50cm for NXT55806 · ×2 · Black -
Cable, USB, 2m for NXT57482 · ×1 · Black -
CD-Rom, for 8527 Mindstorms NXT v1.04493852 · ×1 · [No Color/Any Color] -
![Cone 1 x 1 [No Top Groove]](https://cdn.rebrickable.com/media/parts/elements/458901.jpg)
Cone 1 x 1 [No Top Groove]4589 · ×3 · White -
![Hub, NXT Brick with Dark Bluish Gray Base [Complete Assembly]](https://cdn.rebrickable.com/media/parts/elements/4520887.jpg)
Hub, NXT Brick with Dark Bluish Gray Base [Complete Assembly]53788 · ×1 · Very Light Bluish Gray -
Large Figure Weapon, Claw / Fang, 2 Pin Holes (Visorak Suukorak)50914 · ×4 · Pearl Light Gray -
Motor, NXT53787 · ×3 · Very Light Bluish Gray -
Playmat, Test Mat for Mindstorms NXT40682 · ×1 · [No Color/Any Color] -
Sensor, Light, NXT55969 · ×1 · Very Light Bluish Gray -
Sensor, Sound, NXT55963 · ×1 · Very Light Bluish Gray -
Sensor, Touch, NXT53793 · ×1 · Very Light Bluish Gray -
Sensor, Ultrasonic, NXT53792 · ×1 · Very Light Bluish Gray -
Sticker Sheet for Set 8527-157103 · ×1 · [No Color/Any Color] -
Technic Axle 1.5 with Perpendicular Axle Connector (Technic Pole Reverser Handle)6553 · ×1 · Light Bluish Gray -
Technic Axle 103737 · ×4 · Black -
Technic Axle 123708 · ×2 · Black -
Technic Axle 2 Notched32062 · ×22 · Black -
Technic Axle 34519 · ×17 · Light Bluish Gray -
Technic Axle 3 with Stud6587 · ×4 · Dark Bluish Gray -
Technic Axle 43705 · ×4 · Black -
Technic Axle 532073 · ×7 · Light Bluish Gray -
![Technic Axle 5.5 with Stop [Rounded Short End]](https://cdn.rebrickable.com/media/parts/elements/4508553.jpg)
Technic Axle 5.5 with Stop [Rounded Short End]59426 · ×2 · Dark Bluish Gray -
Technic Axle 63706 · ×4 · Black -
Technic Axle 744294 · ×4 · Light Bluish Gray -
Technic Axle 83707 · ×2 · Black -
Technic Axle and Pin Connector Angled #132013 · ×4 · Black -
Technic Axle and Pin Connector Angled #2 - 180°32034 · ×2 · Black -
Technic Axle and Pin Connector Angled #4 - 135°32192 · ×2 · Black -
Technic Axle and Pin Connector Angled #6 - 90°32014 · ×16 · Black -
Technic Axle and Pin Connector Perpendicular6536 · ×8 · Light Bluish Gray -
Technic Axle and Pin Connector Perpendicular 3L with 2 Pin Holes42003 · ×6 · Dark Bluish Gray -
Technic Axle and Pin Connector Perpendicular 3L with Centre Pin Hole32184 · ×4 · Black -
Technic Axle and Pin Connector Perpendicular Double32291 · ×6 · Dark Bluish Gray -
Technic Axle and Pin Connector Perpendicular Double Split41678 · ×6 · Dark Bluish Gray -
![Technic Axle Connector Double Flexible [Rubber]](https://cdn.rebrickable.com/media/parts/elements/4198367.jpg)
Technic Axle Connector Double Flexible [Rubber]45590 · ×8 · Black -
![Technic Axle Connector Ridged [with x Hole x Orientation]](https://cdn.rebrickable.com/media/parts/elements/4210672.jpg)
Technic Axle Connector Ridged [with x Hole x Orientation]6538b · ×2 · Dark Bluish Gray -
Technic Axle Connector with Axle Hole32039 · ×4 · Black -
Technic Axle Pin with Friction Ridges Lengthwise43093 · ×42 · Blue -
Technic Axle Pin without Friction Ridges Lengthwise3749 · ×4 · Tan -
Technic Axle Towball2736 · ×2 · Light Bluish Gray -
Technic Beam 1 x 11 Thick32525 · ×7 · Very Light Bluish Gray -
Technic Beam 1 x 11.5 Double Bent Thick32009 · ×6 · Dark Bluish Gray -
Technic Beam 1 x 13 Thick41239 · ×4 · Very Light Bluish Gray -
Technic Beam 1 x 15 Thick32278 · ×11 · Very Light Bluish Gray
